The Weidmüller CB9100 Series 9925430000 is a supplemental circuit breaker designed for thermal magnetic operation. It is rated for a current of 10A and a voltage of 277VAC, with a 50VDC rating also available for single-pole applications. This specific model is a single-pole unit.
Designed for easy installation, this circuit breaker mounts directly onto a 35mm DIN-rail. It offers a high interrupting capacity of 10,000A at 277VAC/50VDC, ensuring reliable protection in various electrical systems. The operating temperature range is from -25°C to 55°C.
Key specifications include a thermal magnetic trip type and a lever actuator. The CB9100 series is approved by UL and CSA. This part is suitable for applications requiring robust overcurrent protection in industrial and commercial settings.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 10A.
The voltage rating is 277VAC for a single pole.
This circuit breaker has a single pole configuration.
It is a thermal magnetic type circuit breaker.
It is designed for DIN rail mounting.
The operating temperature range is -25°C to 55°C.
The interrupting capacity is 10,000A at 277VAC/50VDC.
