9921200005 The Weidmüller 9921200005 is a single pole, thermal magnetic circuit breaker rated for 20A and 480VAC. It features a lever actuator and DIN rail mounting.
Mfr Part #:

9921200005

Mfr Name: Weidmüller
Weidmüller
The Weidmüller 9921200005 is a single pole, thermal magnetic circuit breaker rated for 20A and 480VAC. It features a lever actuator and DIN rail mounting.
Stock on Request

9921200005 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Type
Approval Agency
Breaker Type
Current Rating
Current Rating (Amps)
Mounting Type
Number of Poles
Voltage Rating
View Similar Products (0)

9921200005 Description

Short technical summary and product information.

The Weidmüller CB2200 Series 9921200005 is a single-pole circuit breaker designed for reliable circuit protection. It operates on a thermal magnetic principle and is rated for a current of 20A and a voltage of 480VAC.



This circuit breaker is designed for easy installation, featuring a DIN rail mounting type and a lever actuator for trip and reset functions. It is recognized by CSA C22.2 No 235 and UL1077, ensuring compliance with safety standards.



The 9921200005 is suitable for various industrial and commercial applications requiring dependable overcurrent protection. Its robust construction and adherence to recognized standards make it a reliable choice for protecting electrical circuits from faults.

9921200005 Quick Information

Product Type: Circuit Breaker
Series: CB2200 Series
Canonical Name: Weidmüller CB2200 Series Single Pole Thermal Magnetic Circuit Breaker
Subcategory: Thermal Magnetic Circuit Breaker

9921200005 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

9921200005 Features

  • Single pole thermal magnetic circuit breaker.
  • Rated for 20A and 480VAC.
  • DIN rail mounting for easy installation.
  • Lever actuator for trip and reset.
  • UL1077 and CSA C22.2 No 235 recognized.

9921200005 Applications

  • Used in industrial control panels.
  • Protects electrical equipment from overload.
  • Ideal for branch circuit protection.
  • Suitable for distribution applications.
  • Mounts quickly on standard DIN rail.

9921200005 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the voltage rating of the Weidmüller 9921200005?

The voltage rating is 480VAC and 65VDC.

What is the current rating of this circuit breaker?

20A.

How many poles does this circuit breaker have?

1 pole.

What mounting type does this circuit breaker use?

DIN Rail mounting.

What agency approvals does this breaker have?

CSA C22.2 No 235, UL1077, VDE.

What type of actuator does it have?

Lever.

What is the breaker type?

Thermal Magnetic.

9921200005 Alternate Parts

Same form/fit/function or matching attribute configuration across different manufacturers.
View All Alternate Parts
992120
992120
Weidmüller
The Weidmüller 992120 is a single pole, thermal magnetic circuit breaker with a 20A current rating and 480V voltage rating. It features lever actuation and DIN rail mounting.
View Part
