The Weidmüller CB2200 Series 991125 is a single-pole thermal magnetic circuit breaker designed for reliable overcurrent protection. It offers a current rating of 2.5A and a voltage rating of 480VAC, with a DC voltage rating of 65VDC.
This circuit breaker is equipped with a lever-switch trip/reset function and mounts conveniently on a 35mm DIN-rail. It is recognized by UL 1077 and CSA C22.2 No. 235, ensuring compliance with industry standards.
The CB2200 series is available in single, double, and triple pole configurations, with options for normally open (N/O) and normally closed (N/C) auxiliary contacts. This specific model, 991125, is a single-pole unit with a 2.5A rating.
Key features include its thermal magnetic trip mechanism for protection against overloads and short circuits, and its robust construction suitable for various industrial and commercial applications.
The current rating is 2.5A.
The voltage rating is 480V.
It has 1 pole.
It is a Thermal Magnetic type circuit breaker.
It is mounted on a DIN Rail.
It is recognized by CSA C22.2 No 235, UL1077, and VDE.
