This Weidmüller ESX10-T series electronic circuit protector is designed for selective disconnection of 24VDC load systems. It features a 3A current rating and a solid-state breaker type, suitable for DIN rail mounting.
The ESX10-T provides selective load protection with electronic trip characteristics and active current limitation, allowing for the safe connection of capacitive loads up to 20,000 µF. It reliably disconnects on overload with 1.1 x In plus and features a manual ON/OFF button for individual circuit actuation and reset. The unit has a width of 12.5mm and is approved for hazardous areas including ATEX Zone 2 and Class 1 Div 2.
Key electrical specifications include a 24V voltage rating and a 3A current rating. The breaker type is solid state with a slide switch actuator. It supports a wide range of current ratings from 0.5A to 12A and offers overload disconnection at 1.1 x In plus.
This circuit breaker is suitable for applications requiring reliable protection of 24VDC systems, ensuring selective disconnection to prevent complete system shutdown due to a single faulty load. Its compact design and hazardous area approvals make it versatile for industrial environments.
24V DC.
DIN Rail.
The unit is rated for 3A continuous current. The series supports adjustable ratings from 0.5 A to 12 A.
Solid state circuit breaker.
ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, VDE.
1.1 x In plus.
Up to 20,000 µF.
