6720005302
Weidmüller
The Weidmüller 6720005302 is a thermal circuit breaker designed for 24VDC systems. It offers a 2A current rating and features a manual slide switch for operation.
| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating | |
| Width |
The Weidmüller 6720005382 is a single-pole thermal circuit breaker designed for selective load protection in 24VDC systems. It provides active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF. The breaker trips reliably on overload at 1.1 times the rated current.
This circuit breaker features electronic trip characteristics and a manual ON/OFF slide switch for actuation and reset. It includes clear status indication via LED and a status output. The unit is designed for easy wiring with busbar connections and mounts directly onto a DIN rail, with a width of only 12.5 mm.
It is approved by various agencies including UL, CSA, CE, VDE, and ATEX, making it suitable for hazardous area applications like Class 1, Div 2 environments. The breaker also offers optional remote ON/OFF control and electronic reset inputs for enhanced system integration.
24VDC
2A
Thermal
DIN Rail
ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, VDE
Yes, limits current to 1.3 to 1.8 times the selected rated current.
12.5 mm
