| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating | |
| Width |
The Weidmüller ESX10-T series circuit protection device, part number 6720005372, is a thermal circuit breaker designed for 24VDC load systems. It offers selective load protection with electronic trip characteristics and active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF.
This single-pole breaker has a current rating of 12A and a voltage rating of 24VDC. It is designed for reliable overload disconnection and features a manual slide switch for ON/OFF control. The device mounts on a DIN rail for easy installation in control panels.
Status and failure indication are provided through multi-color LEDs. The breaker is approved by various agencies including UL, CSA, VDE, CE, and ATEX, making it suitable for hazardous area applications like Class 1, Div 2.
Key features include active current limitation, manual ON/OFF button, and a width of only 12.5 mm per unit, facilitating compact system designs.
12A
24VDC
Thermal
1 pole
Slide switch
Yes, for capacitive loads up to 20,000 μF
DIN Rail
