This Weidmüller ESX10-T series circuit breaker provides selective load protection with electronic trip characteristics. It is rated for 6A and operates at 24VDC, featuring a manual slide switch actuator.
The breaker is designed for reliable overload disconnection and includes active current limitation, allowing for the safe connection of capacitive loads up to 20,000 µF. It supports remote ON/OFF control and electronic reset inputs, enhancing system flexibility.
Mounting is facilitated via a standard DIN rail, and the unit has a compact width of 12.5 mm. Status indication is provided through LEDs and a status output. The breaker also holds multiple approvals including UL, CSA, CE, VDE, and ATEX, making it suitable for hazardous area applications like Class 1, Div 2.
Key features include its thermal tripping mechanism, single pole design, and robust construction for industrial environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 6A.
The voltage rating is 24 VDC.
It is a thermal circuit breaker.
It is mounted on a DIN rail.
Yes, it features active current limitation for safe connection of capacitive loads up to 20,000 µF.
It is UL/CSA Hazardous area approved for Class 1, Div 2.
