| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Voltage Rating |
The Weidmüller 6720005331 is a single-pole, solid-state electronic circuit protector designed for 12VDC load systems. It provides selective disconnection, responding faster to overloads and short circuits than traditional power supplies.
Key features include active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF. It has a current rating of 1A and a voltage rating of 12VDC. The device is designed for easy installation on DIN rails and includes status indication via an LED and a status output.
This circuit protector is approved for hazardous areas, including Class 1 Div 2 and Zone 2 (ATEX). Its compact design, with a width of only 12.5 mm, saves space in control cabinets. The manual ON/OFF button allows for individual load circuit actuation, and remote operation is possible via control and reset signals.
12VDC.
1A.
DIN Rail.
ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367.
Yes, for safe connection of capacitive loads up to 20,000 μF and on overload/short circuit.
12.5 mm.
Slide Switch.
