The Weidmüller 6720005312 is a thermal circuit breaker designed for selective load protection in 24VDC systems. It features active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF. The breaker provides reliable overload disconnection at 1.1 times the rated current.
This circuit breaker has a current rating of 12A and a voltage rating of 24VDC. It is a single-pole unit with a thermal trip characteristic and a slide switch for manual ON/OFF control. The unit is designed for easy wiring and rail mounting.
It is approved by multiple agencies including ATEX, CE, CSA, UL, and VDE, and is suitable for hazardous areas (UL/CSA Class 1, Div 2). Illumination indicators show status in Green, Orange, and Red.
Key features include active current limitation for capacitive loads, manual ON/OFF button, and clear status indication. The breaker responds quickly to overload or short circuit conditions, offering selective disconnection to prevent system-wide shutdowns.
The voltage rating is 24VDC.
The current rating is 12A.
It is a thermal circuit breaker.
It features a slide switch for actuation.
It is designed for DIN rail mounting.
Yes, it has active current limitation for capacitive loads up to 20,000 μF.
It is approved for UL/CSA Class 1, Div 2 hazardous areas.
