| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating | |
| Width |
The Weidmüller 6720005310 is a single-pole thermal circuit breaker designed for 24VDC applications. It is rated for 10A continuous current and provides reliable overload disconnection at 1.1 x In plus. The breaker features a slide switch actuator and is mounted on a DIN rail, with a compact width of only 12.5 mm per unit.
This circuit breaker includes active current limitation and can handle capacitive loads up to 20,000 μF. It offers clear status and failure indication through an LED and a status output SF or Si contact. Optional control input IN+ enables remote ON/OFF signaling, and an optional electronic reset input RE is available.
The breaker is approved for hazardous areas (UL/CSA Class 1, Div 2) and carries approvals from ATEX, CE, CSA, UL, and VDE. It includes an integral fail-safe element adjusted to the current rating. The status output SF provides a plus-switching signal, connecting Ub to terminal 12, with nominal data of 24VDC / max. 0.2 A (short circuit proof).
The current rating is 10A.
The voltage rating is 24V DC.
It is a thermal circuit breaker with a slide switch actuator.
It is mounted on a DIN rail.
Yes, it has active current limitation.
It can handle capacitive loads up to 20,000 μF.
Yes, it is UL/CSA approved for Class 1, Div 2 hazardous areas.
