| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Load Current | |
| Mounting Type | |
| Number of Poles | |
| Time to Trip | |
| Voltage Rating |
The Weidmüller 6720005308 is a single-pole thermal circuit breaker designed for selective load protection in 24VDC systems. It provides reliable overload disconnection with electronic trip characteristics and active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF.
This circuit breaker has a current rating of 8A and a voltage rating of 24VDC. It features a thermal tripping mechanism and a slide switch actuator for manual ON/OFF control. The unit is designed for DIN rail mounting and has a width of 12.5 mm, facilitating easy integration into control panels.
With approvals including ATEX, CE, CSA, UL, and VDE, the 6720005308 is suitable for various industrial applications, including hazardous areas (Class 1, Div 2). It offers clear status indication through LEDs and status outputs.
The ESX10-T series, to which this part belongs, is engineered to respond faster to overload or short circuit conditions than standard switch-mode power supplies, preventing complete system shutdowns due to a single faulty load.
The Weidmüller 6720005308 circuit breaker has a voltage rating of 24 VDC.
The current rating of the 6720005308 circuit breaker is 8A.
The Weidmüller 6720005308 circuit breaker is designed for DIN rail mounting.
The 6720005308 circuit breaker uses a slide switch actuator.
The Weidmüller 6720005308 circuit breaker is approved by ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, and VDE.
Yes, the 6720005308 circuit breaker features active current limitation for safe connection of capacitive loads up to 20,000 μF.
Yes, the Weidmüller 6720005308 is approved for hazardous areas, specifically Class 1, Div 2.
