| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Voltage Rating | |
| Width |
The Weidmüller 6720005304 is a thermal circuit breaker designed for selective load protection in 24VDC systems. It offers electronic trip characteristics with active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF.
This single-pole breaker has a current rating of 4A and a voltage rating of 24VDC. It features a manual slide switch for ON/OFF control and reset. The breaker provides clear status indication through LEDs and a status output (SF). It is designed for reliable overload disconnection with 1.1 x In plus, ensuring protection even with long load lines or small cable cross-sections.
Mounting is facilitated via DIN rail, and the unit has a width of 12.5 mm. The breaker is approved by multiple agencies including UL, CSA, CE, VDE, and ATEX, and is suitable for hazardous areas (Class 1, Div 2).
Key features include active current limitation, overload disconnection, manual ON/OFF button, and status indication. The ESX10-T series circuit protection is engineered to respond faster to overload or short circuit conditions than typical switch-mode power supplies, preventing complete system shutdowns due to a single faulty load.
The current rating is 4A.
The operating voltage is 24VDC.
It is mounted on a DIN rail.
It is a thermal circuit breaker.
Yes, it features active current limitation for safe connection of capacitive loads up to 20,000 μF.
It is approved by ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, and VDE.
Yes, it is UL/CSA Hazardous area approved for Class 1, Div 2.
