| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating |
The Weidmüller 6720005303 is a single-pole, solid-state circuit breaker rated for 3A and 24VDC. It features electronic trip characteristics and active current limitation, allowing for safe connection of capacitive loads up to 20,000 μF. The breaker provides selective load protection, responding faster to overloads and short circuits than traditional power supplies.
Mounting is facilitated via a standard DIN rail, and the actuator type is a slide switch. The unit offers clear status indication through multi-color LEDs (Green, Orange, Red). It is approved by multiple agencies including ATEX, CE, CSA, UL, and VDE, making it suitable for various industrial applications.
This circuit protector is designed to ensure selective disconnection of 24VDC load systems. In industrial environments where 24VDC power supplies are common, a single faulty load can cause a complete system shutdown. The ESX10-T series, to which this part belongs, responds rapidly to fault conditions, preventing cascading failures and ensuring system uptime. It limits the current to 1.3 to 1.8 times the rated current during overload or short circuit events.
24VDC.
3A.
1.
Solid State.
DIN Rail.
Slide Switch.
ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, VDE.
