6720005361
Weidmüller
The Weidmüller 6720005361 is a 1A, 24VDC thermal circuit breaker designed for DIN rail mounting. It offers active current limitation and clear status indication.
| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating | |
| Width |
The Weidmüller ESX10-T series circuit protection device, part number 6720005301, is engineered for selective disconnection of 24VDC load systems. It provides reliable overload disconnection with electronic trip characteristics and active current limitation, allowing for the safe connection of capacitive loads up to 20,000 μF.
This thermal circuit breaker features a 1A current rating and a 24VDC voltage rating. It is designed for DIN rail mounting and utilizes a slide switch actuator for manual ON/OFF control. The device offers clear status and failure indication through an LED and status output. It is approved by multiple agencies including UL, CSA, CE, VDE, and ATEX, and is suitable for hazardous area applications (Class 1, Div 2).
The ESX10-T responds faster to overload or short circuit conditions than typical switch-mode power supplies due to its active current limitation, which restricts the current to 1.3 to 1.8 times the rated current. This ensures selective disconnection, preventing a single faulty load from shutting down the entire system. The unit has a compact width of 12.5 mm, facilitating ease of wiring and installation on standard rail systems.
24VDC.
1A.
Thermal.
DIN Rail.
ATEX, CE, CSA C22.2 No 14, CSA C22.2 No 142, CSA C22.2 No 213, UL1604, UL508, UL2367, VDE, and Class 1 Div 2 hazardous location rating.
12.5 mm.
Up to 20,000 µF with active current limitation set to 1.3 to 1.8 times the rated current.
