| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
400 pcs
|
400 pcs | On Request | 25 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Termination | |
| Contact Type | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Flammability Rating | |
| Insulation Resistance | |
| Insulator Material | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Packaging Type | |
| Panel Cut-out Thickness | |
| Pitch | |
| Row Spacing | |
| Tape & Reel |
The Würth Elektronik 64902221822 is a rectangular connector housing (plug) from the WR-MPC4 series, designed for wire-to-wire applications. It offers 22 positions arranged in a dual row configuration with a 4.20mm pitch, providing a compact and reliable interconnection solution. The housing features a panel mount design with locking ramp fastening for secure mating. Termination is via crimp contacts (sold separately), allowing for flexible wire assembly. The insulator is molded from white Nylon 66 material with a UL94 V-0 flammability rating, ensuring high flame resistance. Electrical specifications include an insulation resistance greater than 1000 MOhm and a dielectric withstanding voltage of 1500 VAC. The operating temperature range is -40°C to 105°C. The component is RoHS3 compliant and lead free. Recommended panel cut-out thickness is 1.40 ±0.40mm. The housing is packaged in a bag. This connector housing is suitable for general electronics, industrial equipment, and consumer electronics where reliable power or signal connections are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.27 | $1.27 |
| 10+ | $1.24 | $1.24 |
| 50+ | $1.15 | $1.15 |
| 100+ | $1.00 | $1.00 |
| 500+ | $0.94 | $0.94 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
22 positions.
4.20mm (0.165").
Panel mount.
-40°C to 105°C.
UL94 V-0.
Yes, it is RoHS3 compliant.
Crimp termination.
