| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Amps) | |
| Finish | |
| Halogen Free | |
| Line Side Conductor Size (UL) | |
| Line Side Connection Type | |
| Line Side Connections Per Pole | |
| Load Side Conductor Size (UL) | |
| Load Side Connection Type | |
| Load Side Connections Per Pole | |
| Load Side Wire | |
| Material | |
| Max Current Rating (IEC) | |
| Max Current Rating (UL/CSA) | |
| Max Working Voltage (IEC) | |
| Max Working Voltage (UL) | |
| Mounting Type | |
| Number of Poles | |
| Type | |
| Voltage |
The ERIFLEX 569010 (UD-80A) is a single pole power distribution block designed for distributing power in industrial and commercial electrical systems. It is rated for 85A continuous current per IEC standards and 80A per UL/CSA standards, with a maximum working voltage of 600V (UL) / 1000V (IEC).
The block accepts a #4 AWG line side conductor (UL) and provides 4 line side connections per pole with screw terminals. The load side accommodates up to 7 connections per pole and accepts wire sizes from #4 to #16 AWG, also using screw connections.
Constructed with a tinned copper conductor block and thermoplastic housing, the UD-80A is designed for DIN rail or panel mounting. It is RoHS3 compliant, halogen free, and conforms to EN 45545 with HL3 (R23) and HL2 (R22) classifications for railway fire safety.
The IEC current rating is 85A and the UL/CSA current rating is 80A.
The maximum working voltage is 600V per UL standards and 1000V per IEC standards.
This block has 1 pole.
Both line side and load side connections are screw type.
The block can be mounted on a DIN rail or directly to a panel with screws.
