| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.0314 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a current rating of 5A and a voltage rating of 240 VAC, with a DC rating of 60 VDC. The breaker features a thermal tripping mechanism and a rocker actuator for easy operation.
This circuit breaker is suitable for panel mounting and has a mechanical lifetime of 50,000 switching cycles. It operates within a temperature range of -30°C to 60°C. The device meets IP40 degree of protection on the front side and has a conditional short circuit capacity of 2 kA at 240 VAC.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its robust design and thermal-magnetic tripping capabilities ensure effective protection against overloads and short circuits.
The rated voltage is 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The rated current range is 0.05 to 20 A AC, with magnetic tripping up to 16 A.
This circuit breaker has 2 poles.
The allowable operating temperature is -30 °C to 60 °C.
Yes, it is RoHS3 Compliant.
