| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter 4430.3425 is a 2-pole thermal circuit breaker with a 7A current rating and a voltage rating of 240 VAC or 60 VDC. It is designed for panel mounting and features rocker actuation.
This circuit breaker offers thermal overload protection and a positively trip-free release. It has a mechanical lifetime of 50,000 switching cycles and an AC overload rating of a minimum of 40 trips at 6x Ir. The operating temperature range is -10 °C to 55 °C.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment. It meets IP40 degree of protection on the front side.
The breaker is rated for 240VAC and 60VDC.
-10°C to 55°C.
Thermal tripping type.
IP40 front side, IP54 with protection cover.
2 poles.
Panel mount.
1 kA at 240VAC (conditional short circuit capacity Inc).
