The Schurter Inc. 4430.1328 is a 2-pole thermal circuit breaker with a rocker actuation type, suitable for panel mounting. It provides thermal overload protection with a rated current of 15A and a rated voltage of 240 VAC or 60 VDC.
Key technical specifications include a conditional short circuit capacity of 1 kA AC and a short circuit capacity of up to 300A. The breaker offers a mechanical lifetime of 50,000 switching cycles and operates within a temperature range of -10°C to 55°C.
This circuit breaker is designed for applications requiring reliable overcurrent protection. Its robust construction and thermal tripping mechanism make it suitable for various industrial and equipment uses. The IP40 degree of protection ensures protection against solid objects, with an option for IP54 when a factory-mounted protection cover is used.
Approvals include CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, and UL1077, indicating compliance with relevant safety standards.
240 VAC and 60 VDC.
-10 °C to 55 °C.
15 A.
Thermal.
2 poles.
IP40 in standard configuration, IP54 with factory-mounted protection cover.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
