This Schurter Inc. 4430.1158 is a thermal circuit breaker designed for reliable overload protection in various applications. It features a 2-pole configuration and a rocker actuation type, suitable for panel mounting.
The circuit breaker has a rated voltage of 240 VAC and 60 VDC, with a rated current range of 0.05 to 20 A AC. It offers a conditional short circuit capacity of 1 kA and a short circuit capacity Icn of up to 300A. The device is built for durability with a mechanical lifetime of 50,000 switching cycles.
Environmental specifications include a degree of protection of IP40 on the front side, which can be increased to IP54 with a factory-mounted protection cover. The operating temperature range is -10 °C to 55 °C, and it has undergone vibration and shock resistance testing according to IEC standards.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning. Its robust design and thermal tripping mechanism ensure safety and longevity in demanding environments.
The rated voltage is 240 VAC and 60 VDC.
The allowable operating temperature is -10 °C to 55 °C.
The RoHS status is RoHS3 Compliant.
The MSL is 1 Unlimited.
The REACH status is REACH Unaffected.
This circuit breaker has 2 poles.
It uses rocker actuation.
