5600200220
Molex
Molex 5600200220 is a 2-position, single row, surface mount male pin header with a 2.00mm pitch. It features a shrouded 4-wall design with latch lock and solder retention for secure PCB mounting.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Tape & Reel |
The Molex 43045-2008 is a male pin header from the Micro-Fit 3.0 series, designed for surface mount right angle mounting. It has 8 contacts arranged in 2 rows with a 3mm pitch and 3mm row spacing. The header features a black Liquid Crystal Polymer (LCP) housing and brass contacts with gold plating on the mating area (0.76µm) and tin plating on the posts. The insulation height is 5.9mm, and the overall contact length is 5.9mm. The contact post length is 3.2mm. It is rated for 5A of current and 250V voltage. The operating temperature range is -40 to 105°C. The fastening type is latch lock, and it includes board guide and solder retention features. These headers are commonly used in power and signal applications requiring a compact, reliable interconnect. The right angle orientation allows for low-profile connections perpendicular to the PCB. The surface mount design enables automated assembly. The gold plating ensures reliable mating over multiple cycles. The latch lock provides secure connection to mating receptacles. The board guide and solder retention features aid in alignment and improve solder joint reliability.
| Qty | Low | High |
|---|---|---|
| 1+ | $11.41 | $11.41 |
| 10+ | $10.12 | $10.12 |
| 25+ | $9.73 | $9.73 |
| 50+ | $9.34 | $9.34 |
| 100+ | $8.82 | $8.82 |
| 250+ | $8.05 | $8.05 |
| 500+ | $7.88 | $7.88 |
| 1,000+ | $6.69 | $6.69 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 8 contacts in a 2-row configuration.
The mating pitch is 3mm, and the row spacing is also 3mm.
The maximum current rating is 5A.
The maximum voltage rating is 250V.
It is surface mount, right angle.
The operating temperature range is -40 to 105°C.
The contacts are brass with gold plating on the mating area (0.76µm) and tin plating on the posts.
