| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| CTI (Comparative Tracking Index) | |
| Clamping Range (Maximum @ IEC) | |
| Clamping Range (Maximum @ UL) | |
| Color | |
| Conductor Outlet Direction | |
| Current | |
| Depth | |
| Failure Rate | |
| Features | |
| Flammability Rating | |
| Height | |
| Insulating Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Mating Orientation | |
| Max Relative Humidity During Storage | |
| Mounting Type | |
| Net Weight | |
| Number of Levels | |
| Number of Solder Pins per Pole | |
| Operating Temperature Range | |
| Package Quantity | |
| Package Type | |
| Pitch | |
| Positions Per Level | |
| Rated Current (Nominal @ IEC) | |
| Rated Current (Nominal @ UL) | |
| Rated Voltage (Nominal @ IEC) | |
| Rated Voltage (Nominal @ UL) | |
| SVHC Present | |
| Screwdriver Blade | |
| Solder Eyelet Hole Diameter | |
| Solder Pin Dimensions | |
| Solder Pin Length | |
| Storage Temperature | |
| Storage Temperature Range | |
| Stripping Length | |
| Touch-safe Protection | |
| Voltage | |
| Width | |
| Wire Gauge | |
| Wire Termination |
The Weidmüller LUFS 10.00/06/180V 5.0SN BK BX is a high-performance PCB terminal block from the OMNIMATE Power series. It offers 6 positions with a 10mm pitch and a 180° conductor outlet direction, designed for vertical wire entry relative to the PCB.
Electrical ratings are 1000V/76A per IEC and 600V/57A per UL, with a clamping range accepting 0.5-16 mm² solid or stranded wire (AWG 18-4). The PUSH IN spring connection system allows tool-less insertion of solid conductors or ferruled stranded wires; a push button actuator opens the contact point for release.
The terminal block is housed in black Wemid (PA) insulating material with a V-0 flammability rating per UL 94. It features three solder pins per pole with a 5mm pin length and 1.6mm eyelet hole diameter, suitable for through-hole soldering. Operating temperature range is -40°C to 120°C.
The pitch is 10.00 mm (0.394 in).
It has 6 positions per level, with 1 level.
IEC rating: 1000 V, 76 A. UL rating: 600 V, 57 A.
Through hole (THT solder connection).
IEC: 0.5 - 16 mm². UL: AWG 18 - AWG 4.
-40°C to 120°C.
UL 94 V-0.
