| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
70 pcs
|
70 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuation Force | |
| Actuator Length | |
| Actuator Material | |
| Actuator Type | |
| Bushing Thread | |
| Circuit | |
| Contact Timing | |
| Contacts | |
| Current Rating (Amps) | |
| Features | |
| Illumination | |
| Insulation Resistance | |
| Mounting Type | |
| Operating Temperature | |
| Panel Cutout Dimensions | |
| Storage Temperature | |
| Switch Function | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating |
This TE Connectivity toggle switch, part number 2-1571920-3, is a Double Pole Double Throw (DPDT) device suitable for various applications. It offers a contact rating of 6A at 125VAC and 4A at 28VDC, with an initial contact resistance of 20 milliohms maximum.
The switch features a panel mount design with a 1/4-40 bushing thread and a circular panel cutout of 6.40mm diameter. The actuator is a standard round type with a length of 10.49mm, and the termination style is solder lug. The terminals are epoxy sealed for added durability.
Environmental specifications include an operating temperature range of -20°C to 80°C and a storage temperature range of -40°C to 80°C. The case material is Thermoset 94V-0, and the contacts are gold flash over silver. The switch is RoHS3 compliant, has an MSL of 1, and is REACH unaffected.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The switch has a voltage rating of 125 VAC and 250 VAC.
The current rating at 125 VAC is 6 A.
The initial contact resistance is 20 milliohms maximum.
The switch operates within a temperature range of -20°C to +80°C.
Contacts are gold flash over silver.
The switch has a DPDT circuit configuration.
