| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
83 pcs
|
83 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
21 pcs
|
21 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Type | |
| Circuit | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| Height Above Board | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Termination Style | |
| Voltage Rating | |
| Washable |
The TE Connectivity 1825360-3 is a Single Pole Single Throw (SPST) DIP switch designed for through-hole mounting. It operates at a voltage rating of 24VDC and can handle a current of 100mA. The switch features a standard slide actuator with a raised level and a pitch of 2.54mm (0.100").
With 4 positions, this DIP switch offers flexibility in circuit configuration. It has a contact finish of gold and is constructed from copper alloy. The operating temperature range is from -30°C to 85°C. The switch is washable and has a height above the board of 5.80mm.
This component is suitable for various electronic applications requiring manual circuit selection. Its through-hole mounting ensures a secure connection on printed circuit boards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage is 24VDC.
The operating temperature range is -30°C to 85°C.
It is mounted using the through-hole method.
The current rating is 100mA.
It provides a Single Pole Single Throw (SPST) circuit.
