1813440000 Weidmüller 1813440000 is a 5-position, shrouded male header with 10.16mm pitch. It offers a through-hole solder connection and silver-plated contacts.
Mfr Part #:

1813440000

Available from 1 distributors
Mfr Name: Weidmüller
Weidmüller
Weidmüller 1813440000 is a 5-position, shrouded male header with 10.16mm pitch. It offers a through-hole solder connection and silver-plated contacts.
✓ Total Stock: 36 pcs

1813440000 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
36 pcs
On Request
36 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1813440000 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Header Orientation
Insulation Resistance
Lead Style
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Positions Per Level
Termination Style
Type
Voltage
Weight
View Similar Products (0)

1813440000 Description

Short technical summary and product information.

The Weidmüller 1813440000 is a PCB plug-in connector, male header from the OMNIMATE Power series (SU 10.16HP). It features 5 positions in a single row with a pitch of 10.16mm (0.400 inches). The header is shrouded on all four sides for touch-safe protection, achieving IP20 when mated.



This header is designed for high-current applications, with a UL current rating of 60A and an IEC rating of 78.3A. The voltage rating is 300V UL and 1000V IEC. The contact mating finish is silver, and the solder pin length is 3.5mm, optimized for wave soldering. The header orientation is vertical (180° plug-in direction).



The mounting type is through-hole (THT) with solder termination. The insulating material is PBT GF with a flammability rating of V-0. The operating temperature range is -50°C to 120°C. The product is packaged in a box of 36 pieces.

1813440000 Quick Information

Product Type: Terminal Block Header
Series: SU 10.16HP
Canonical Name: Weidmüller SU 10.16HP/05/180G 3.5AG BK BX Header, 5 Positions, 10.16mm Pitch, Through Hole, Silver
Subcategory: Male Header, Shrouded

1813440000 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1813440000 Features

  • 5 positions in a single row with 10.16mm pitch.
  • Rated for 60A UL and 78.3A IEC current.
  • Shrouded header with IP20 touch-safe protection.
  • Silver-plated contacts for reliable conductivity.
  • Through-hole solder termination with 3.5mm pins.

1813440000 Applications

  • Used in power distribution units and industrial controls.
  • Suitable for high-current PCB connections in automation.
  • Ideal for power supply and motor drive applications.

1813440000 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the Weidmüller 1813440000 have?

5 positions.

What is the pitch of this header?

10.16 mm (0.400 inches).

What is the current rating of the 1813440000?

UL rating: 60 A; IEC rating: 78.3 A.

What voltage rating does this part have?

UL: 300 V; IEC: 1000 V.

What is the mounting type for this connector?

Through hole (THT) with solder termination.

What is the operating temperature range?

-50°C to 120°C.

What is the contact plating?

Silver.
