The Weidmüller BLZ 5.08/11/180 SN BK BX (part number 1527310000) is an 11-position female plug-in connector designed for free-hanging (in-line) mounting. It features a clamping yoke (screw) termination system that accepts solid or flexible wires from 0.2 to 2.5 mm² (26–12 AWG). The plug offers a 5.08mm pitch and a 180° wire entry direction, simplifying routing in tight spaces.
Rated at 15A and 300V, this connector is suitable for moderate-current PCB connection applications. The insulating body is molded from black PBT (UL 94 V-0) with a CTI of >= 200. Contacts are copper alloy with tin plating for reliable conductivity. The design includes retention latches on the non-wire side for secure mating with header pins.
For installation, the recommended stripping length is 7 mm, and the clamping screw (M2.5) must be tightened to a torque of 0.4–0.5 Nm using a 0.6 x 3.5 mm screwdriver. The connector achieves IP20 finger-safe protection per DIN VDE 0470.
This plug has 11 positions with a 5.08mm (0.200 inch) pitch.
The rated current is 15 A (IEC). CSA and UL 1059 rating is 10 A. Maximum current with no pins at 20°C is 19 A (per IEC).
Rated voltage is 300 V (general). IEC ratings: 400 V (II/2), 320 V (III/2), 250 V (III/3). CSA and UL 1059 rated at 300 V.
It supports free hanging (in-line) mounting with a 180° wire entry direction (straight through plug).
It accepts 26 to 12 AWG (0.13–3.31 mm² clamping range) and requires a 7 mm stripping length.
