| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
87 pcs
|
87 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Header Orientation | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage |
The Weidmüller 1512810000 is a 4 position terminal block header from the SL 5.08 series. It features a 5.08mm pitch and a right angle orientation with male pins shrouded on two sides. The black housing is designed for through hole mounting with solder termination, and the contacts have a tin mating finish.
Electrical ratings include 15A current capacity and 300V voltage rating, with an operating temperature range of -20°C to 100°C. The solder pin length is 4.5mm, making it suitable for standard PCB thicknesses.
This header is commonly used in industrial control, automation, and power distribution applications where a reliable and compact wire-to-board connection is required. The 90° angle allows for low-profile mating with plug connectors.
This header has 4 positions.
The pitch is 5.08mm (0.200 inches).
The current rating is 15 A.
The voltage rating is 300 V.
The mounting type is through hole.
The operating temperature range is -20°C to 100°C.
The header orientation is 90°, right angle.
