| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
61 pcs
|
61 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Board Thickness | |
| Body Finish | |
| Body Material | |
| Center Contact Material | |
| Connector Style | |
| Connector Type | |
| Contact Termination | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Frequency | |
| Frequency - Max | |
| Housing Color | |
| Impedance | |
| Mounting Type | |
| Number of Ports | |
| Operating Voltage | |
| Shield Termination | |
| Tape & Reel | |
| Termination Style |
The Cinch 142-0701-851 is an SMA end launch jack receptacle designed for board edge mounting. It features a female socket connector with threaded fastening and a solder tab contact termination. The connector has a 50 Ohm impedance and supports frequencies up to 18 GHz, making it suitable for RF applications. The body is gold plated with a nickel plated finish, and the center contact is made of beryllium copper. The board thickness requirement is 1.57 mm (0.062 in). This uncabled receptacle has a VSWR specification of N/A as per datasheet. It is RoHS3 compliant and has an MSL of 1 (unlimited). The connector is ideal for use in RF test equipment, telecommunications, and other high-frequency systems where a reliable edge-mount SMA connection is required.
Board edge, end launch.
335 Vrms maximum at sea level.
50 Ohms.
18 GHz.
Threaded.
Solder tab.
Beryllium copper.
