| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
67 pcs
|
67 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Features | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions or Pins (Grid) | |
| Pitch | |
| Termination | |
| Termination Style | |
| Type |
The 14-823-90 is a 14-position DIP IC socket manufactured by Aries Electronics. It features a 0.3" (7.62mm) row spacing and a 2.54mm (0.100") pitch, making it suitable for standard DIP packages. The socket uses a closed frame design with a polyamide (PA46) housing and phosphor bronze contacts with a 10.0µin gold finish.
This socket is designed for through-hole mounting with a right-angle, horizontal orientation. The solder termination ensures reliable connections in prototyping and production environments. The gold contact finish provides good corrosion resistance and reliable electrical performance.
The closed frame construction offers mechanical protection for the IC during insertion and removal. The PA46 housing material provides good thermal and mechanical properties for demanding applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $11.63 | $11.63 |
| 10+ | $9.88 | $9.88 |
| 25+ | $9.26 | $9.26 |
| 50+ | $8.82 | $8.82 |
| 100+ | $8.40 | $8.40 |
| 250+ | $7.87 | $7.87 |
| 500+ | $7.50 | $7.50 |
| 1,000+ | $7.14 | $7.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 14-823-90 has 14 positions arranged as 2 rows of 7 pins.
The pitch is 2.54mm (0.100").
Through-hole, right-angle, horizontal mounting.
Gold finish with 10.0µin (0.25µm) thickness.
Polyamide (PA46), Nylon 4/6.
