| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
21 pcs
|
21 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Features | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Wire Gauge or Range |
The Weidmüller 1283660000 is a 21-position terminal block plug designed for reliable wire-to-board connections in industrial control and automation systems. It features female socket contacts with a 5.08mm pitch and a screw clamp (clamping yoke) termination style, accommodating wire sizes from 0.2 to 2.5mm².
This plug is rated for 10A current and 300V voltage, with an operating temperature range of -50°C to 120°C. The free hanging (in-line) mounting allows flexible installation without a fixed panel or PCB. The orange housing and tin-plated contacts provide durability and easy identification.
Retention latches on the non-wire side ensure secure mating with the corresponding header. The 180° wire entry simplifies wiring in tight spaces. This component is suitable for use in power distribution, control panels, and industrial equipment requiring a robust, field-serviceable connection.
It has 21 positions.
The pitch is 5.08mm (0.200 inches).
It is rated for 10A and 300V.
It uses free hanging (in-line) mounting.
It accepts wire sizes from 0.2 to 2.5mm².
The operating temperature range is -50°C to 120°C.
It uses screw clamp (clamping yoke) termination.
