| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
230 pcs
|
230 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Type | |
| Body Material | |
| Circuit | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| Features | |
| Height Above Board | |
| Length | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Termination Style | |
| Voltage Rating | |
| Washable |
The TE Connectivity 1-1571983-4 is a slide-actuated DIP switch designed for reliable electrical switching applications. It features a Single Pole Single Throw (SPST) circuit configuration, capable of handling a current rating of 25mA and a voltage rating of 24VDC.
This switch is designed for surface mounting with gull wing termination style, ensuring secure and stable connections on printed circuit boards. The contact finish is gold, providing good conductivity and corrosion resistance. The operating temperature range is -30°C to 85°C, making it suitable for various environmental conditions.
Key features include a tape seal for protection during handling and soldering processes, and a flush or recessed actuator level for ease of use. The dimensions include a length of 0.444 inches (11.28mm) and a height above board of 0.091 inches (2.30mm). The pitch between positions is 0.050 inches (1.27mm).
With a mechanical and electrical life of 1,000 cycles, this DIP switch is built for durability in applications requiring precise and dependable switching operations.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The voltage rating is 24VDC.
The current rating is 25mA.
It features a Single Pole Single Throw (SPST) circuit.
The operating temperature range is -30°C to 85°C.
It is designed for surface mounting.
It uses a gull wing termination style.
The pitch is 1.27mm (0.050").
