| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
84 pcs
|
84 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
28 pcs
|
28 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Style | |
| Actuator Type | |
| Circuit | |
| Contact Base Material | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| Features | |
| Height Above Board | |
| Housing Color | |
| Housing Material | |
| Length | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Operating Temperature Range | |
| Pitch | |
| Switch Type | |
| Termination Style | |
| UL Flammability Rating | |
| Voltage Rating | |
| Washable |
The TE Connectivity 1-1571983-0 is a Single Pole Single Throw (SPST) DIP switch designed for reliable switching applications. It features 8 positions and a surface mount termination style with gull wing leads, facilitating automated assembly processes. The switch is constructed with a Polyphenylene Sulfide (PPS) housing and copper alloy contacts plated with gold over nickel for mating areas and gold for solder tails, ensuring durability and conductivity.
This low-profile DIP switch operates within a temperature range of -30°C to 85°C and has a tape seal for protection. Electrical characteristics include a voltage rating of 50 VDC (as per datasheet) or 24 VDC (as per manufacturer page) and a contact current rating of 0.1 A (datasheet) or 25mA (manufacturer page). The pitch between positions is 1.27 mm. The housing material is Polyphenylene Sulfide (PPS), and it carries a UL 94V-0 flammability rating.
Designed for applications requiring precise control, the 1-1571983-0 is suitable for various electronic systems. Its mechanical and electrical life are rated for 1,000 cycles each. The switch is washable and features a recessed rocker actuator. Packaging is provided in tubes, with 40 units per tube.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The voltage rating is 50 VDC according to the datasheet and 24 VDC according to the manufacturer page.
The TE Connectivity 1-1571983-0 DIP switch has 8 positions.
The operating temperature range is -30°C to 85°C.
The contact mating area plating material is Gold, and the solder tail contact plating is Gold over Nickel.
Yes, the TE Connectivity 1-1571983-0 is RoHS compliant.
