The Harting 09451251100 is a shielded RJ45 Cat5 modular plug designed for industrial Ethernet applications. It features 8 positions with 4 contacts (8p4c) and uses IDC termination for solid or stranded wires with conductor cross-sections from 0.22 to 0.32 mm². The plug is fully shielded with 360° shielding contact for reliable signal integrity.
The housing is made of polycarbonate (PC) in black color and provides IP65/IP67 protection against dust and water ingress. It supports data rates up to 100 Mbit/s (Cat5 Class D) and operates over a temperature range of -40 to +70 °C. The cable diameter range is 5 to 9 mm, and the plug has a length of 101.65 mm.
This plug is part of the Han3A series and is suitable for use in harsh industrial environments where robust connectivity is required. It is RoHS, REACH, and ELV compliant, and comes with a net weight of 60 g.
8 positions with 4 contacts (8p4c).
IDC (Insulation Displacement Connection).
Fully shielded with 360° shielding contact.
IP65/IP67 - dust tight, water resistant, waterproof.
10 Mbit/s and 100 Mbit/s.
-40 to +70 °C.
5 to 9 mm.
