ZX-XH2.54-2PZZ The Megastar ZX-XH2.54-2PZZ is a wire to board connector featuring a 2.5mm pitch and 2 positions. It is designed for through-hole mounting.
Mfr Part #:

ZX-XH2.54-2PZZ

Available from 1 distributors
Mfr Name: Zhaoxing
Zhaoxing
The Megastar ZX-XH2.54-2PZZ is a wire to board connector featuring a 2.5mm pitch and 2 positions. It is designed for through-hole mounting.
✓ Total Stock: 4 pcs

ZX-XH2.54-2PZZ Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
4 pcs
On Request
4 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ZX-XH2.54-2PZZ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Material
Contact Plating
Current Rating
Lead Spacing
Lead Style
Mounting Type
Number of Pins
Number of Rows
Operating Temperature
Pitch
SVHC Present
Voltage Rating
View Similar Products (0)

ZX-XH2.54-2PZZ Description

Short technical summary and product information.

The Megastar ZX-XH2.54-2PZZ is a wire to board connector from the XH series, designed for reliable electrical connections. It features a 2.5mm pitch, accommodating 2 positions within a 1x2 pin structure. This connector is rated for a current of 3A and a voltage of 250V, making it suitable for various power and signal applications.



The connector utilizes a through-hole mounting type for secure attachment to a PCB. The housing is constructed from durable PA66 plastic in a yellow color. Contact points are made from copper alloy and plated with tin for good conductivity and corrosion resistance. The operating temperature range is -25°C to +85°C.



Key mechanical dimensions include a board width of 5.75mm, a board length of 7.5mm, and a board height of 7mm. The ZX-XH2.54-2PZZ is designed for applications requiring a compact and robust wire to board connection solution.

ZX-XH2.54-2PZZ Quick Information

Product Type: Wire To Board Connector
Series: XH
Canonical Name: Megastar ZX-XH2.54-2PZZ Wire To Board Connector
Subcategory: Headers, Male Pins

ZX-XH2.54-2PZZ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ZX-XH2.54-2PZZ Features

  • 2.5mm pitch wire to board connector.
  • Features 2 positions in a 1x2 structure.
  • Rated for 3A current and 250V voltage.
  • Through hole mounting for secure connection.
  • Operates within -25°C to +85°C range.

ZX-XH2.54-2PZZ Applications

  • Ideal for power supply connections.
  • Suitable for signal transmission.
  • Used in consumer electronics.
  • Applicable in industrial controls.

ZX-XH2.54-2PZZ FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of the ZX-XH2.54-2PZZ?

2.5 mm.

How many positions does it have?

2 positions.

What is the current rating?

3 A.

What is the voltage rating?

250 V.

What is the mounting type?

Through hole.

What is the operating temperature range?

-25°C to +85°C.

What are the contact material and plating?

Copper alloy with tin plating.
