| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The TDK Corporation ZWS50-15 is a 50W AC/DC converter designed for ITE (Commercial) applications. It offers a universal input voltage range of 85-265 VAC and a nominal output voltage of 15V at 3.5A.
This open frame converter is suitable for chassis mounting and boasts an efficiency of 81%. Key features include adjustable output, DC input capability, load sharing, and Power Factor Correction (PFC).
The operating temperature range is -10°C to 60°C with derating, and it has a 2-year warranty. The unit is designed for convection cooling and meets various safety and EMC standards including CE, cURus, TUV, EN55022-B, FCC Class B, and VCCI-B.
The ZWS50-15 has a nominal output voltage of 15V.
The ZWS50-15 has a power rating of 50W.
The ZWS50-15 accepts a universal AC input voltage range of 85-265 VAC.
The operating temperature range for the ZWS50-15 is -10°C to 60°C, with derating applied from 50°C to 60°C.
The ZWS50-15 supports chassis mounting.
The ZWS50-15 has a typical efficiency of 81%.
