| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,524 pcs
|
2524 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| SVHC Present | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Cosel ZUW60512 is an isolated DC-DC converter module designed for commercial ITE applications. It provides dual ±12V outputs, each capable of delivering 250mA, with a typical efficiency of 75%.
Operating from an 18V to 36V input range, the ZUW60512 offers line regulation of 60mV max, load regulation of 600mV max, and ripple and noise of 150mVp-p max. The module includes overcurrent protection (OCP) for reliable operation.
The converter is housed in a 5-DIP through-hole package, measuring 44.5mm x 28.0mm x 7.0mm. It operates over a temperature range of -20°C to 71°C with derating. The input-to-output isolation is rated at 500VAC.
This module is suitable for use in commercial information technology equipment and other systems requiring isolated dual-output power supplies.
18V to 36V
Dual ±12V (output 1: +12V, output 2: -12V)
250mA per output
75% typical
-20°C to 71°C (with derating)
5-DIP Module, through-hole mounting
RoHS3 compliant (unverified)
