| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Weight |
The TDK Corporation ZPS40-12 is an open-frame AC-DC power supply designed for various applications. It delivers 40W of power with a single 12V output, providing a stable power source for electronic devices.
Key electrical specifications include a wide range AC input from 90-264VAC or 120-370VDC, and an efficiency rating of up to 84%. The unit offers line regulation of ±0.5% and load regulation of ±1%, with voltage accuracy of ±1%. It features continuous hiccup mode for short circuit protection and overvoltage protection typically set at 110-130% of nominal voltage.
With dimensions of 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm), this power supply is suitable for chassis mounting. The operating temperature range is 0°C to 70°C, with derating applied from 50°C. It complies with global safety agency standards including UL60950, CSA60950, EN60950, and carries the CE Mark (LVD). EMI performance meets EN55022-B and FCC Class B standards, with immunity to EN61000-4 series.
This power supply is ideal for ITE (Commercial) applications requiring a reliable and efficient power conversion solution. It comes with a two-year warranty.
The ZPS40-12 provides a 12V output voltage at 3.34A.
The ZPS40-12 has a power rating of 40W.
The efficiency of the ZPS40-12 is 84%.
The ZPS40-12 operates from 0°C to 70°C.
The ZPS40-12 has safety approvals including UL60950, CSA60950, EN60950, and CE Mark (LVD).
