ZL9117MIRZ The ZL9117MIRZ is a 17A digital non-isolated point-of-load DC-DC converter module from Renesas. It features PMBus control, auto-compensation, and a wide input voltage range of 4.5V to 13.2V.
Mfr Part #:

ZL9117MIRZ

Available from 1 distributors
Mfr Name: Renesas
Renesas
The ZL9117MIRZ is a 17A digital non-isolated point-of-load DC-DC converter module from Renesas. It features PMBus control, auto-compensation, and a wide input voltage range of 4.5V to 13.2V.
✓ Total Stock: 2,458 pcs

ZL9117MIRZ Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
2,458 pcs
On Request
2458 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ZL9117MIRZ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Applications
Automotive Grade
Control Features
Current
Features
Halogen Free
Height
Industrial Grade
Length
Medical Grade
Military Grade
Mounting Type
Number of Outputs
Operating Temperature
SVHC Present
Supplier Device Package
Tape & Reel
Type
Voltage
Width
View Similar Products (0)

ZL9117MIRZ Description

Short technical summary and product information.

The ZL9117MIRZ is a complete digital switch mode power supply module from Renesas, integrating a high-performance digital PWM controller, power MOSFETs, inductor, and passive components. It delivers up to 17A of output current with an adjustable output voltage from 0.6V to 3.6V, set via external resistors or PMBus commands.



This module operates over an input voltage range of 4.5V to 13.2V and includes built-in auto-compensation algorithms, eliminating manual compensation design. Protection features include overcurrent (OCP), overtemperature (OTP), overvoltage (OVP), and undervoltage lockout (UVLO).



The ZL9117MIRZ is housed in a thermally enhanced 21-PowerBQFN module measuring 15.0mm x 15.0mm with a low profile of 3.5mm, suitable for surface mount assembly. It is RoHS compliant and designed for commercial ITE applications.

ZL9117MIRZ Quick Information

Product Type: DC-DC Converter Module
Series: ZL9117M
Canonical Name: ZL9117MIRZ Non-Isolated PoL Module, Digital
Subcategory: Digital DC-DC Converter

ZL9117MIRZ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 3
REACH Status: REACH Unaffected
Lead Free: No

ZL9117MIRZ Features

  • 17A output current capability.
  • PMBus digital control interface.
  • Auto-compensating PID filter design.
  • Wide input voltage 4.5V to 13.2V.
  • Surface mount 21-PowerBQFN package.

ZL9117MIRZ Applications

  • Ideal for server and telecom power.
  • Used in industrial and medical equipment.
  • General purpose point of load regulation.

ZL9117MIRZ FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range of the ZL9117MIRZ?

The input voltage range is 4.5V to 13.2V.

What output voltage and current can the ZL9117MIRZ provide?

It provides an adjustable output from 0.6V to 3.6V and up to 17A.

What package does the ZL9117MIRZ come in?

It is housed in a 21-PowerBQFN module (21-QFN 15x15mm) with a height of 3.5mm.

What is the operating temperature range?

The operating temperature range is -40°C to 85°C.

Is the ZL9117MIRZ RoHS compliant?

Yes, the datasheet confirms RoHS compliance.

What control interface does the ZL9117MIRZ support?

It supports the PMBus digital control interface.

What protection features are included?

It includes overcurrent (OCP), overtemperature (OTP), overvoltage (OVP), and undervoltage lockout (UVLO) protection.
