| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Lead Style |
The Mini-Circuits ZFSC-4-3-BNC is a 4-way power splitter, a crucial component in RF systems for dividing a signal into multiple paths. This device operates efficiently within a broad frequency range, from 10 MHz up to 300 MHz, making it versatile for various applications.
With a standard impedance of 50 ohms, the ZFSC-4-3-BNC ensures compatibility with most RF equipment and transmission lines. Its 4-way configuration allows for the distribution of an input signal to four separate outputs, maintaining signal integrity across the specified frequency band.
This power splitter is suitable for a wide array of telecommunications, test and measurement, and radar systems where signal division is required. Its robust design and performance characteristics make it a reliable choice for engineers designing complex RF architectures.
While specific details on power handling and insertion loss are not provided, the core functionality of signal splitting within the 10-300 MHz range is clearly defined. The component is manufactured by Mini-Circuits, a recognized leader in RF and microwave components.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The frequency range is 10 to 300 MHz.
The impedance is 50 ohms.
It has four ways.
It belongs to the Test Leads - BNC Interface category.
