YM120D200N200 PTC resettable fuse with 265V maximum voltage and 192mA hold current. Radial disc package with 5.08mm lead spacing.
Mfr Part #:

YM120D200N200

Available from 1 distributors
Mfr Name: Amphenol Thermometrics
Amphenol Thermometrics
PTC resettable fuse with 265V maximum voltage and 192mA hold current. Radial disc package with 5.08mm lead spacing.
✓ Total Stock: 5 pcs
$ Price Range: $2.45

YM120D200N200 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
5 pcs
On Request
5 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

YM120D200N200 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Height
Lead Spacing
Mounting Type
Operating Temperature
Resistance
Tape & Reel
Type
Voltage
View Similar Products (0)

YM120D200N200 Description

Short technical summary and product information.

The YM120D200N200 is a PTC thermistor from Amphenol Thermometrics, designed for general purpose over-current, over-voltage, and direct over-temperature protection. It features a ceramic barium titanate element with a silicone resin coating, housed in a radial disc package for through-hole mounting. Key specifications include a maximum operating voltage of 265V rms, a hold current of 192 mA, and a resistance of 20 ohms at 25°C with ±20% tolerance. The nominal switch temperature is 120°C, and the ambient temperature range at maximum voltage is 0 to +55°C. The component has a diameter of 9.50mm and a thickness of 4.50mm, with a lead spacing of 5.08mm. It is suitable for automatic PCB insertion and offers excellent stability and fail-safe operation. The device is available in loose-packed quantities of 500 per box, with bandolier options for automated assembly.

YM120D200N200 Quick Information

Product Type: PTC Resettable Fuse
Series: YM120
Canonical Name: PTC Thermistor, YM120 Series, 192 mA Hold, 265 V, 20 Ohm, Radial Disc
Subcategory: Over-Current Protection

YM120D200N200 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

YM120D200N200 Estimated Pricing

Qty Low High
2,500+ $2.45 $2.45

Estimated market price range - modelled values for guidance only, not live distributor offers.

YM120D200N200 Features

  • Radial leaded disc package for through-hole mounting.
  • Rated for 265V rms maximum operating voltage.
  • 192 mA hold current for overcurrent protection.
  • 20 ohm resistance at 25°C with ±20% tolerance.
  • Switch temperature nominal 120°C.

YM120D200N200 Applications

  • Used in general purpose over-current protection circuits.
  • Suitable for over-voltage and direct over-temperature protection.
  • For use in power supplies, transformers, and motors.
  • Ideal for automatic PCB insertion with lead spacing of 5.08mm.

YM120D200N200 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the hold current of the YM120D200N200?

192 mA.

What is the maximum operating voltage?

265V rms.

What is the package type?

Radial, Disc through-hole.

What is the switch temperature?

120°C nominal.

What is the resistance at 25°C?

20 ohms with ±20% tolerance.

What is the standard packaging quantity?

500 pieces per box (loose-packed).

What is the ambient temperature range at maximum voltage?

0 to +55°C.
