| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
617 pcs
|
617 pcs | On Request | 1 | On Request | On Request | 1806+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Features | |
| Height | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Resistance | |
| Supplier Device Package | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
This Vishay Dale Y1121562R000A9R is a high-precision surface mount resistor from the SMRxD series, utilizing Bulk Metal® Foil technology. It offers a resistance value of 562 Ohms with a tight tolerance of ±0.05% and a low temperature coefficient of resistance (TCR) of ±2ppm/°C.
The resistor is designed for demanding applications, featuring a power rating of 0.25W (1/4W) and an operating temperature range from -55°C to 175°C. Its construction includes features like non-inductive design and moisture resistance, contributing to its reliability.
The component is housed in a 2512 J-Lead package, suitable for surface mounting. Its flexible terminations help reduce stress transference from the PCB, enhancing durability in various environments. The dimensions are approximately 5.99mm in length and 3.20mm in width, with a height of 2.79mm.
Key electrical characteristics include a voltage coefficient of less than 0.1 ppm/V and a load life stability of ±0.005% over 2000 hours at 70°C. These specifications make it suitable for precision instrumentation, military, and high-end audio applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.02 | $0.02 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 562 Ohms.
The tolerance is ±0.05%.
The power rating is 0.25W (1/4W).
The temperature coefficient is ±2ppm/°C.
The operating temperature range is -55°C to 175°C.
The resistor is in a 2512 J-Lead package.
