XTR116 The Texas Instruments XTR116 is a precision current output converter designed for 4mA to 20mA signals. It operates over a wide loop supply range and comes in an SOIC-8 package.
Mfr Part #:

XTR116

Available from 1 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments XTR116 is a precision current output converter designed for 4mA to 20mA signals. It operates over a wide loop supply range and comes in an SOIC-8 package.
✓ Total Stock: 45,200 pcs
$ Price Range: $0.99

XTR116 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
45,200 pcs
On Request
45200 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

XTR116 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Operating Temperature
Quiescent Current
SVHC Present
View Similar Products (0)

XTR116 Description

Short technical summary and product information.

The Texas Instruments XTR116 is a precision current output converter designed to transmit analog 4mA to 20mA signals over an industry-standard current loop. It provides accurate current scaling and output current limit functions.



Key electrical specifications include a low quiescent current of 200µA, a 5V regulator for external circuits, and a precise 4.096V reference voltage for sensor excitation. The device boasts low span error (0.05%) and low nonlinearity error (0.003%). It supports a wide loop supply range from 7.5V to 36V.



The XTR116 is specified for operation over the extended industrial temperature range of -40°C to +85°C. It is housed in a compact SOIC-8 package, suitable for surface mount applications.



This device is a fundamental building block for smart sensors utilizing 4mA to 20mA current transmission, finding applications in field transmitters, flow transmitters, temperature transmitters, and PLC, DCS, & PAC systems. It is also compatible with HART modems.

XTR116 Quick Information

Product Type: Current-Loop Transmitter
Canonical Name: XTR116 4-20mA Current-Loop Transmitter
Subcategory: 4-20mA signal conditioners

XTR116 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

XTR116 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

XTR116 Features

  • Precision 4-20mA current loop transmitter.
  • Features 4.096V reference voltage.
  • Wide 7.5V to 36V loop supply range.
  • Low quiescent current of 200µA.
  • Operates from -40°C to +85°C.

XTR116 Applications

  • Used in field transmitters and sensors.
  • Suitable for flow transmitters.
  • Applicable for temperature transmitters.
  • Integrates with PLC, DCS, and PAC.
  • Compatible with HART modem.

XTR116 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range for the XTR116?

7.5V to 36V.

What is the operating temperature range of the XTR116?

-40°C to +85°C.

What package is the XTR116 available in?

SOIC-8 package measuring 4.90mm x 3.90mm.

What is the quiescent current consumption of the XTR116?

200µA typical.

Does the XTR116 include a voltage regulator?

Yes, it integrates a 5V regulator for external circuits.

What reference voltage does the XTR116 provide?

4.096V reference for sensor excitation.

What is the accuracy of the XTR116?

Span error of 0.05% and nonlinearity error of 0.003%.
