| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
80 pcs
|
80 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Insulation | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Mounting Type | |
| Must Operate Voltage | |
| Must Release Voltage | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Switching Voltage | |
| Termination Style |
The TE Connectivity XT314012 is a general purpose relay designed for various applications. It features a SPDT (1 Form C) contact form and a robust contact rating of 16A.
This relay operates with a 12VDC coil voltage and has a coil current of 33.3 mA. Key electrical specifications include a must operate voltage of 8.4 VDC and a must release voltage of 1.2 VDC. The operate time is 9 ms, and the release time is 6 ms. The switching voltage is rated up to a maximum of 400VAC.
Designed for ease of integration, the XT314012 features socketable mounting and plug-in termination style. It is built with Silver Nickel (AgNi) contact material for reliable performance. The operating temperature range is -40°C to 70°C, and it utilizes Class F coil insulation.
Environmental compliance includes RoHS3 compliance, an MSL of 1 Unlimited, and REACH unaffected status. These specifications make the XT314012 suitable for a wide range of industrial and commercial applications requiring dependable switching.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage is 12 VDC.
The contact rating is 16 A.
It has a SPDT (1 Form C) contact form.
The maximum switching voltage is 400 VAC.
The operating temperature range is -40°C to 70°C.
It is socketable.
