| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,000 pcs
|
5000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Bandwidth | |
| Charge Injection | |
| Crosstalk | |
| Function | |
| Mounting Type | |
| Number of Circuits | |
| Operating Temperature | |
| Supplier Device Package | |
| Switch Circuit | |
| Voltage |
The Diodes Incorporated PI3A2268ZMEX is an analog switch designed for interface applications. It features a 2:1 multiplexer/demultiplexer circuit with a SPDT switch configuration, offering two circuits per device. The switch provides a low on-state resistance of 750mOhm and exhibits a channel-to-channel matching of 50mOhm. Its operating temperature range is -40°C to 85°C.
With a single supply voltage range of 1.65V to 4.2V, the PI3A2268ZMEX is suitable for various electronic designs. Key electrical characteristics include a -3dB bandwidth of 84MHz, fast switch times of 13ns (Ton) and 12ns (Toff), and low crosstalk of -110dB at 1MHz. The device also features low leakage current and charge injection.
Packaged in a 10-UFQFN format, the PI3A2268ZMEX is designed for surface mounting. The component is ROHS3 compliant, indicating adherence to environmental standards. Its lifecycle status is obsolete.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.26 | $1.26 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum on-state resistance of the PI3A2268ZMEX is 750mOhm.
The PI3A2268ZMEX operates with a single supply voltage ranging from 1.65V to 4.2V.
The operating temperature range for the PI3A2268ZMEX is -40°C to 85°C.
The PI3A2268ZMEX is supplied in a 10-UFQFN package.
Yes, the PI3A2268ZMEX is ROHS3 Compliant.
The -3dB bandwidth of the PI3A2268ZMEX is 84MHz.
The switch times for the PI3A2268ZMEX are a maximum of 13ns for Ton and 12ns for Toff.
