XRT7300IV The Maxlinear XRT7300IV is a Line Interface Unit (LIU) designed for E3, DS3, or SONET STS-1 applications. It operates from a single +5V supply and is available in a 44-pin TQFP package.
Mfr Part #:

XRT7300IV

Available from 1 distributors
Mfr Name: Maxlinear
Maxlinear
The Maxlinear XRT7300IV is a Line Interface Unit (LIU) designed for E3, DS3, or SONET STS-1 applications. It operates from a single +5V supply and is available in a 44-pin TQFP package.
✓ Total Stock: 3,566 pcs
$ Price Range: $1.26

XRT7300IV Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
3,566 pcs
On Request
3566 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

XRT7300IV Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Function
Interface
Lead Spacing
Mounting Type
Number of Circuits
Operating Temperature
Supplier Device Package
Supplier Package
Voltage
View Similar Products (0)

XRT7300IV Description

Short technical summary and product information.

The XRT7300IV from Maxlinear is an integrated Line Interface Unit (LIU) designed for E3 (34.368 Mbps), DS3 (44.736 Mbps), or SONET STS-1 (51.84 Mbps) applications. This single-chip solution incorporates both a line transmitter and receiver, simplifying system design.



In the transmit direction, the XRT7300IV encodes data into B3ZS or HDB3 formats and converts it into appropriate pulse shapes for transmission over coaxial cable. The receiver performs equalization, clock recovery, decoding from B3ZS or HDB3 formats, and checks for line code violations. It also includes a 4-wire microprocessor serial interface for accessing on-chip command registers.



Key features include support for E3/DS3/STS-1 jitter tolerance requirements, full loop-back capability, transmit and receive power-down modes, and full redundancy support. The device requires a single +5V power supply and operates within a temperature range of -40°C to +85°C.



The XRT7300IV is housed in a 44-pin TQFP package, suitable for surface mounting. It is ideal for applications such as CSU/DSU equipment, PCM test equipment, fiber optic terminals, and multiplexers interfacing with E3, DS3, or SONET STS-1 networks.

XRT7300IV Quick Information

Product Type: Telecom Interface IC
Canonical Name: XRT7300IV E3/DS3/STS-1 Line Interface Unit
Subcategory: Telecom

XRT7300IV Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

XRT7300IV Estimated Pricing

Qty Low High
1+ $1.26 $1.26

Estimated market price range - modelled values for guidance only, not live distributor offers.

XRT7300IV Features

  • Supports E3, DS3, and STS-1 rates.
  • Integrated line transmitter and receiver.
  • Features equalization and clock recovery.
  • Operates from a single +5V supply.
  • Available in a 44-pin TQFP package.

XRT7300IV Applications

  • Used in E3, DS3, or SONET STS-1 networks.
  • Suitable for CSU/DSU equipment.
  • Applicable for PCM test equipment.
  • Ideal for fiber optic terminals.
  • Used in multiplexer applications.

XRT7300IV FAQs

5 frequently asked questions generated from this part’s specifications.
What operating voltage does the XRT7300IV require?

The XRT7300IV requires a 4.75V to 5.25V operating voltage.

What is the operating temperature range for the XRT7300IV?

The operating temperature range for the XRT7300IV is -40°C to +85°C.

What package type is the XRT7300IV available in?

The XRT7300IV is available in a 44-TQFP package.

What data rates does the XRT7300IV support?

The XRT7300IV supports E3 (34.368 Mbps), DS3 (44.736 Mbps), and SONET STS-1 (51.84 Mbps) rates.

What encoding formats does the XRT7300IV support for transmission?

The XRT7300IV supports B3ZS and HDB3 encoding formats.
