XLM2DG12W The SunLED Corporation XLM2DG12W is a green, through-hole LED with a 5mm clear lens. It operates at 20mA and features a wavelength of 520nm.
Mfr Part #:

XLM2DG12W

Available from 1 distributors
Mfr Name: SunLED Corporation
SunLED Corporation
The SunLED Corporation XLM2DG12W is a green, through-hole LED with a 5mm clear lens. It operates at 20mA and features a wavelength of 520nm.
✓ Total Stock: 369 pcs
$ Price Range: $0.06

XLM2DG12W Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
369 pcs
On Request
369 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

XLM2DG12W Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Configuration
Current
Height (Max)
Lens Color
Lens Size
Lens Style
Lens Transparency
Millicandela Rating
Mounting Type
Supplier Device Package
Viewing Angle
Voltage
Wavelength
View Similar Products (0)

XLM2DG12W Description

Short technical summary and product information.

The SunLED Corporation XLM2DG12W is a discrete through-hole LED designed for various indication applications. This component features a green light emission with a typical wavelength of 520nm and a clear lens.



Key electrical characteristics include a nominal forward voltage of 3.2V and a standard operating current of 20mA. The LED offers a high typical luminous intensity of 18990mcd and a viewing angle of 20 degrees. The lens size is 5mm, T-1 3/4, with a maximum height of 8.60mm.



This LED is suitable for applications requiring a distinct green light output. Its through-hole mounting type ensures secure placement on printed circuit boards. The component is specified with a RoHS3 Compliant status, MSL 1 Unlimited rating, and REACH Unaffected status.

XLM2DG12W Quick Information

Product Type: Through-Hole LED
Series: XLxx12x
Canonical Name: SunLED Corporation XLM2DG12W Green 5mm Water Clear Through-Hole LED
Subcategory: Discrete LED

XLM2DG12W Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

XLM2DG12W Estimated Pricing

Qty Low High
1+ $0.06 $0.06

Estimated market price range - modelled values for guidance only, not live distributor offers.

XLM2DG12W Features

  • Green through-hole LED with clear lens.
  • 520nm wavelength for distinct green light.
  • High intensity: 18990mcd typical.
  • 20mA standard operating current.
  • 20° viewing angle.

XLM2DG12W Applications

  • Used as indicator lights in electronic devices.
  • Suitable for status indication in control panels.
  • Ideal for green LED signaling applications.
  • Used in low-voltage illumination and display systems.
  • Suitable for through-hole LED applications in various industries.

XLM2DG12W FAQs

5 frequently asked questions generated from this part’s specifications.
What is the typical luminous intensity of the XLM2DG12W LED?

The typical luminous intensity is 18990mcd at 20mA.

What is the forward voltage for the XLM2DG12W LED?

The nominal forward voltage is 3.2V.

What is the wavelength of the XLM2DG12W LED?

The wavelength is 520nm.

What is the viewing angle of the XLM2DG12W LED?

The viewing angle is 20°.

What is the package type for the XLM2DG12W LED?

The package is T-1 3/4, and it is a through-hole mounting type.
