XLG-200-L-AB The MEAN WELL XLG-200-L-AB is a 200W constant current LED driver. It features a wide input range and IP67 rating for outdoor applications.
Mfr Part #:

XLG-200-L-AB

Available from 1 distributors
Mfr Name: MWL
MWL
The MEAN WELL XLG-200-L-AB is a 200W constant current LED driver. It features a wide input range and IP67 rating for outdoor applications.
✓ Total Stock: 24 pcs

XLG-200-L-AB Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
24 pcs
On Request
24 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

XLG-200-L-AB Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Dimensions
Input Voltage
Output Current
Output Voltage
SVHC Present
Wattage
View Similar Products (0)

XLG-200-L-AB Description

Short technical summary and product information.

The MEAN WELL XLG-200-AB series, including the XLG-200-L-AB model, offers 200W constant current LED drivers designed for robust performance.



Key electrical specifications include a wide input voltage range of 100-305VAC and an output current of 700mA, with an output voltage range of 142-285V. The driver is equipped with 3-in-1 dimming functionality and comprehensive protection features such as OVP, SCP, OCP, and OTP.



Built with a metal case and an IP67 rating, this LED driver is suitable for outdoor applications. It also features surge protection up to 6KV/4KV and a long operational life of over 50,000 hours, backed by a 5-year warranty.



Safety standards include UL8750, CSA C22.2 No. 250.13-12, and ENEC EN61347-1, among others. EMC standards are met with compliance to EN55015 (CISPR15) and EN61000-3-2.

XLG-200-L-AB Quick Information

Product Type: LED Driver
Series: XLG-200-AB
Canonical Name: MEAN WELL XLG-200-L-AB Constant Current LED Driver
Subcategory: 0-10V Dimmable

XLG-200-L-AB Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

XLG-200-L-AB Features

  • 200W constant current LED driver.
  • Wide 100-305VAC input range.
  • IP67 rated metal case for outdoor use.
  • 3-in-1 dimming function included.
  • Overload and short circuit protection.

XLG-200-L-AB Applications

  • Ideal for street and area lighting.
  • Suitable for flood and landscape lighting.
  • Use in industrial high-bay fixtures.
  • Designed for outdoor and damp locations.
  • Compatible with constant current LED modules.

XLG-200-L-AB FAQs

5 frequently asked questions generated from this part’s specifications.
What is the wattage of the MEAN WELL XLG-200-L-AB LED driver?

The MEAN WELL XLG-200-L-AB LED driver has a wattage of 200W.

What is the input voltage range for the XLG-200-L-AB?

The input voltage range for the XLG-200-L-AB is 100-305VAC.

What is the output current of the XLG-200-L-AB?

The output current for the XLG-200-L-AB is 700mA.

What is the operating temperature range for this LED driver?

The working temperature range for the XLG-200-L-AB is -40 to +95 °C.

Is the MEAN WELL XLG-200-L-AB suitable for outdoor use?

Yes, the XLG-200-L-AB has a metal case with an IP67 rating, making it suitable for outdoor applications.
