| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
950 pcs
|
950 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Features | |
| Industrial Grade | |
| Medical Grade | |
| Number of Outputs | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage |
The Advanced Energy Excelsys UltiMod XGT is a single-output DC power module designed for use with UX4 and UX6 configurable power supply chassis. It provides a nominal 48V output at up to 6A, with a total power of 288W.
The module features remote On/Off control, remote sense compensation, and a power good signal for system monitoring. The output voltage is user-adjustable from 28V to 58V, with a dynamic trim range of 8.0V to 58.0V, offering flexibility for a variety of loads.
As part of the UltiMod family, the XGT benefits from high efficiency (up to 91%), active PFC, and medical safety certifications including UL/EN60601-1 3rd edition and 2 MOPP isolation. The module is hot-swappable and field-configurable, suiting demanding medical, industrial, and test equipment applications.
The nominal output voltage is 48V, with a user-adjustable range of 28-58V.
The maximum output current is 6A.
Yes, it features remote On/Off control and remote sense compensation.
RoHS3 compliance is indicated but unverified; treat as low confidence.
