| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
278 pcs
|
278 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lead Spacing | |
| Mounting Type | |
| Number of Gates | |
| Number of I | |
| Number of LABs | |
| Number of Logic Elements | |
| Operating Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Total RAM Bits | |
| Voltage |
The XCV1600E-6BG560C from Advanced Micro Devices is a high-density, 1.8V FPGA belonging to the Virtex-E family. It offers a substantial 2,188,742 system gates and 34,992 logic elements, supported by 7,776 logic array blocks (LABs).
This FPGA provides 404 I/O pins and features 589,824 total RAM bits, including 1 Mb of distributed RAM and up to 832 Kb of synchronous internal block RAM. It operates within a voltage range of 1.71V to 1.89V and has an operating temperature range of 0°C to 85°C.
The device is manufactured using a 0.18 μm process technology and comes in a 560-MBGA surface mount package. Its internal performance reaches 130 MHz, with an aggregate bandwidth exceeding 100 Gb/s. It also includes eight digital Delay-Locked Loops (DLLs) for clock management.
Key features include support for various differential signaling standards like LVDS, BLVDS, and LVPECL, and high-performance interfaces to external memories such as ZBT SRAMs and DDR SDRAMs. The architecture is designed for flexibility, balancing speed and density with dedicated carry logic and multiplier support.
| Qty | Low | High |
|---|---|---|
| 1+ | $21.20 | $21.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The XCV1600E-6BG560C FPGA has 34,992 logic elements.
The XCV1600E-6BG560C has 404 I/O pins.
The operating voltage range for the XCV1600E-6BG560C is 1.71V to 1.89V.
The XCV1600E-6BG560C is supplied in a 560-MBGA package.
The operating temperature range for this FPGA is 0°C to 85°C.
The XCV1600E-6BG560C has a total of 589,824 RAM bits.
The internal performance of the XCV1600E-6BG560C is 130 MHz.
