XC9572-10PC44C The Xilinx XC9572-10PC44C is a 5-volt In-System Programmable CPLD featuring 72 macrocells and operating over a temperature range of 0°C to 70°C. It comes in a 44-PLCC package.
Mfr Part #:

XC9572-10PC44C

Available from 1 distributors
Mfr Name: Xilinx
Xilinx
The Xilinx XC9572-10PC44C is a 5-volt In-System Programmable CPLD featuring 72 macrocells and operating over a temperature range of 0°C to 70°C. It comes in a 44-PLCC package.
✓ Total Stock: 2 pcs

XC9572-10PC44C Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
2 pcs
On Request
2 pcs On Request 1 On Request On Request 00G/99G/ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

XC9572-10PC44C Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Lead Spacing
Lead Style
Mounting Type
Tape & Reel
View Similar Products (0)

XC9572-10PC44C Description

Short technical summary and product information.

The Xilinx XC9572-10PC44C is a Complex Programmable Logic Device (CPLD) from the XC9500 series. This component operates at 5 volts and offers 72 macrocells, making it suitable for various embedded applications.



Key electrical specifications include an internal voltage supply range of 4.75V to 5.25V and an operating temperature range from 0°C to 70°C. The device is In-System Programmable (ISP), allowing for flexible design and updates.



Packaged in a 44-PLCC (16.59x16.59) format, the XC9572-10PC44C is designed for surface mount applications. Its standard package quantity is 26 units, typically supplied in a tube.



This CPLD is noted as 'NOT RECOMMENDED for NEW DESIGN', suggesting that while functional, newer alternatives may be preferred for new projects.

XC9572-10PC44C Quick Information

Product Type: CPLD
Series: XC9500
Canonical Name: XC9572-10PC44C Complex Programmable Logic Device
Subcategory: CPLD

XC9572-10PC44C Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

XC9572-10PC44C Features

  • 72 macrocells for complex logic designs.
  • 1600 gates for moderate logic density.
  • In-system programmable for flexible updates.
  • 5V internal supply voltage operation.
  • 44-PLCC surface mount package.

XC9572-10PC44C Applications

  • Ideal for glue logic in embedded systems.
  • Used in telecommunications control circuits.
  • Suitable for industrial automation controllers.
  • Perfect for prototyping and low-volume production.

XC9572-10PC44C FAQs

6 frequently asked questions generated from this part’s specifications.
What is the operating voltage of the XC9572-10PC44C?

The internal supply voltage is 5V (4.75V to 5.25V).

What is the package type of the XC9572-10PC44C?

It is a 44-PLCC (16.59x16.59) surface mount package.

What is the operating temperature range?

0°C to 70°C.

How many macrocells does the XC9572-10PC44C have?

72 macrocells.

Is the XC9572-10PC44C programmable?

Yes, it is in-system programmable.

How many gates does the XC9572-10PC44C have?

1600 gates.
